Specifications | |
Controller |
Intel Ethernet Controller X550AT2 |
Baffle Height |
Full height and half height |
Power Consumption |
Typical Power11.2W; Maximum Power13.0W |
System Support |
Windows ServerX 2012 R2; Windows Server 2012 R2 Core; Windows Server 2012; Windows Server 2012 Core; Windows Server 2008 R2; Windows Server 2008 R2 Core; LinuxX Stable Kernel version 2.6.32/3x; LinuxX RHEL 6.5 and RHEL 7.0; LinuxX SLES 11 SP3 and SLES 12; FreeBSDX 9 and FreeBSDX 10; UEFIX 2.1; UEFIX 2.3; VMware ESXi 5.1(Limited Functionality); VMware ESXi 5.5 |
Ports |
Dual 10GBASE-T RJ45 Port |
Bus type |
PCIe v3.0 (8.0GT/s) (2.0 and 1.1 compatible) |
Bus Width |
x4 lane PCle operable in x8 and x16 slots |
Data rate supported per port |
10 GbE/1 GbE/100MbE |
LED Indicators |
Link(green/orange bright)and ACTIVITY( green flashing) Link Rate(green=10Gbps;orange=1Gbps/100Mbps) |
Virtual Machine Device Queues (VMDq) |
Offloads data sorting from the hypervisor to silicon, improving data throughput and CPU usage QoS feature for Tx data by providing round-robin servicing and preventing head-of- line blocking Sorting based on MAC addresses and VLAN tags |
Support for PCI-SIG SR-IOV |
Up to 64 VFs per port |
IEEE 802.1Q VLAN Support with VLAN Tag |
Ability to create multiple VLAN segments |
VXLAN Stateless Offloads |
A framework for overlaying virtualized layer 2 networks over layer 3 networks. VXLAN enables users to create a logical network for VMs across different networks |
NVGRE Stateless Offloads |
Network Virtualization using Generic Routing Encapsulation. The encapsulation of an Ethernet Layer 2 Frame in IP that enables the creation of virtualized Layer 2 subnets that can span physical Layer 3 IP networks |
Intel® Flow Director |
Yes |
MSI-X |
Yes |
FPP - 64 VFs Per Port |
Yes |
Tx/Rx IP SCTP TCP and UDP Checksum Offloading (lPv4IPv6) Capabilities |
Yes |
Tx TCP Segmentation Offload |
Yes |
SNMP and RMON |
Yes |
Protocol Support |
IEEE 802.1QX VLANs IEEE 802.3 2005X flow control support compatible 10 GbE and 1 GbE Ethernet/ 802.3ap (KX/KX4) Specification compatible the 10 GbE 802.3ap (KR) Specification compatible 1000BASE-BX Specification |
PXE |
Yes |
WoL |
No |
Jumbo frames |
15.5 KB |
Ethernet power management |
Yes |
Storage |
iSCSI, NFS,FCoE,SMB |
Operating temperature |
0 °C to 55 °C (32 °F to 131 °F) |
Storage temperature |
-40 °C to 70 °C (-40 °F to 158 °F) |
Storage humidity |
Maximum: 90% non-condensing relative humidity at 35 °C |
Air Flow |
Minimum of 1 50 LFM required |
Certifications |
FCC CE RoHS |
Size(LxWxH)mm |
137X69X1.6 mm |
