Specifications
|
Controller
|
Intel(R) I350
|
Cable
|
1G SFP / AOC/ DAC
|
Cable Type
|
1000Base-SX/1000Base-LX/1000Base-T
|
Bracket
|
Full-height Bracket
|
Power(max)
|
3.6W
|
Operating System Support
|
Windows 10
|
Windows 8/8.1
|
Windows 7
|
Windows Vista
|
Windows XP
|
Windows Server 2019 /R2
|
Windows Server 2016 /R2
|
Windows Server 2012 /R2
|
Windows Server 2008 /R2
|
Windows Server 2003 /R2
|
Linux kernel 2.4.x/2.6.x/3.x/4.x or later
|
FreeBSD 7.x or later
|
UnixWare / Open Unix 8
|
Sun Solaris 9/10/11 or later
|
VMware ESX/ESXI 5.x/6.x or later
|
Connector
|
6 * 1G SFP
|
PCIe
|
PCI Express v2.1 (2.5GT/s & 5.0GT/s) x4;compatible x8、x16
|
Speed
|
1000Mbps
|
Power Supply
|
PCIe
|
Technical Parameters
|
Ethernet Power Management
|
Yes
|
IEEE Standard
|
IEEE 802.3z 1000BASE-X Gbit/s Ethernet
IEEE 802.3x Full Duplex and flow control IEEE 802.3az Energy Efficient Ethernet
IEEE 802.3ad Link aggregation for parallel links
IEEE 802.1Q VLAN
|
PXE
|
Yes
|
DPDK
|
Yes
|
Jumbo Frame
|
Yes
|
iSCSI
|
Yes
|
WOLE
|
No
|
FCoE
|
No
|
Environment Features
|
Operating Temperature
|
0℃ to 55℃(32℉ to 131℉)
|
Storage Temperature
|
-40℃to 70℃ (-40℉ to 158℉)
|
Storage Humidity
|
90% non condensing under 35℃
|
Certificate
|
FCC A, UL, CE, VCCI, BSMI, CTICK, KCC
|
LED Indicator
|
LED Indicator
|
1000Mbps: Green Link,Yellow Blink
|
Driver
|
Windows
|
Intel(R) I350 Gigabit Fiber Network Connection
|
Linux
|
Intel Corporation I350 Gigabit Fiber Network Connection (rev 01)
|
Physical Features
|
PCB size(mm)
|
165*68*1.6
|
Weight(g)
|
112
|
